Snapper ZTR PTO clutch fitment is easiest when you start with the part number. If your original clutch, parts diagram, or mower lookup points to 7063246YP, 7063246, or 63246, you are likely in the Snapper / Murray 7063246YP replacement path.
This guide helps route select Snapper ZTR Yard Cruiser, Snapper ZTR Scrambler, Snapper ZTR Twin Stick, and related Murray applications to the correct aftermarket replacement PTO clutch. Confirm the original clutch number, deck size, crankshaft bore, pulley alignment, rotation, connector, and anti-rotation setup before ordering.
Find Your Snapper 7063246YP PTO Clutch Path
Table tip: On mobile, swipe sideways to view the full fitment table.
| Model / Search Path | Deck Reference | Series Reference | Common Part Numbers | Replacement Path |
|---|---|---|---|---|
| Snapper ZTR Yard Cruiser | 42 inch | Series 3, Series 4 | 7063246YP, 7063246, 63246 | 7063246YP PTO Clutch Replacement |
| Snapper ZTR Yard Cruiser | 48 inch | Series 3, Series 4 | 7063246YP, 7063246, 63246 | 7063246YP PTO Clutch Replacement |
| Snapper ZTR Twin Stick | 42 inch | Series 6 | 7063246YP, 7063246, 63246 | 7063246YP PTO Clutch Replacement |
| Snapper ZTR Twin Stick | 48 inch | Series 6 | 7063246YP, 7063246, 63246 | 7063246YP PTO Clutch Replacement |
| Snapper ZTR Scrambler | 42 inch | Series 5, Series 6 | 7063246YP, 7063246, 63246 | 7063246YP PTO Clutch Replacement |
| Snapper ZTR Scrambler | 48 inch | Series 5, Series 6 | 7063246YP, 7063246, 63246 | 7063246YP PTO Clutch Replacement |
| Murray 63246 / 7063246 path | Select applications | Verify by model and clutch number | 63246, 7063246, 7063246YP | 7063246YP PTO Clutch Replacement |
Important fitment note: This table is a routing guide, not a universal interchange list. Snapper and Murray PTO clutch fitment can change by model year, series, deck size, engine package, wiring connector, and previous repairs. Confirm fitment before ordering.
Not sure this is the right number path? If your clutch label shows a Warner, Xtreme, Husqvarna, Dixon, John Deere, Country Clipper, or other cross-reference number instead of Snapper 7063246YP or 63246, use the 7063246YP PTO Clutch Cross Reference Guide before ordering.
7063246YP / 63246 PTO Clutch Replacement Path
The 7063246YP PTO Clutch Replacement is the lead replacement path for select Snapper ZTR and Murray applications using the 7063246YP / 7063246 / 63246 clutch family.
- Replacement for OEM part numbers: 7063246YP, 7063246, 63246
- Common Snapper routing: select ZTR Yard Cruiser, ZTR Scrambler, and ZTR Twin Stick applications
- Common Murray routing: select applications using the 63246 / 7063246 path
- Crankshaft bore: 1 inch
- Pulley class: 5.3 inch / 5.35 inch class
- Rotation: Counter-clockwise from pulley side
Pulley measurement note: aftermarket catalogs may round this pulley size as 5.3 inch, 5.35 inch, or 5-3/8 inch. The key installation checks are pulley alignment, belt tracking, bore size, rotation, wiring connector, and anti-rotation setup.
Snapper ZTR Yard Cruiser PTO Clutch Fitment Notes
Snapper ZTR Yard Cruiser models are one of the strongest direct search paths for the 7063246YP / 63246 clutch family. The most common Yard Cruiser references in this path are 42 inch and 48 inch Series 3 and Series 4 machines.
- ZTR Yard Cruiser 42 inch Series 3
- ZTR Yard Cruiser 42 inch Series 4
- ZTR Yard Cruiser 48 inch Series 3
- ZTR Yard Cruiser 48 inch Series 4
If your Yard Cruiser parts lookup, original clutch label, or stamped number points to 7063246YP, 7063246, or 63246, compare the replacement clutch specs before ordering.
Snapper ZTR Scrambler PTO Clutch Fitment Notes
Snapper ZTR Scrambler models are also commonly tied to the 7063246YP / 63246 replacement path on select 42 inch and 48 inch applications.
- ZTR Scrambler 42 inch Series 5
- ZTR Scrambler 42 inch Series 6
- ZTR Scrambler 48 inch Series 5
- ZTR Scrambler 48 inch Series 6
Do not order by “Scrambler” alone. Confirm the deck size, series, original clutch number, bore, pulley alignment, rotation, wiring connector, and anti-rotation setup before installing the replacement.
Snapper ZTR Twin Stick PTO Clutch Fitment Notes
Snapper ZTR Twin Stick applications in this path are commonly associated with Series 6 machines using 42 inch or 48 inch deck references.
- ZTR Twin Stick 42 inch Series 6
- ZTR Twin Stick 48 inch Series 6
If your Twin Stick application routes to 63246, 7063246, or 7063246YP, use the 7063246YP PTO Clutch Replacement product page as the lead replacement path.
Murray 63246 and 7063246 PTO Clutch Path
The same clutch path is also commonly searched under Murray numbers 63246, 7063246, and 7063246YP. If your Murray application uses one of these numbers, compare the replacement clutch specs before ordering.
- Murray number path: 63246, 7063246, 7063246YP
- Lead replacement path: 7063246YP PTO Clutch Replacement
- Key specs to confirm: 1 inch bore, 5.3 / 5.35 inch pulley class, counter-clockwise rotation from pulley side
Warner and Aftermarket Cross-References
Some Snapper and Murray owners find a Warner or aftermarket number on the original clutch instead of a Snapper or Murray part number. These numbers can help route the replacement path.
- Warner: 5219-15
- Xtreme: X0122, X0122-K, X0395, X0395-K
Other Warner and aftermarket numbers may appear in broader marketplace cross-reference lists, but they should be handled carefully. Use the 7063246YP PTO Clutch Cross Reference Guide to compare related OEM and aftermarket numbers, or the Warner 5219 PTO Clutch Cross Reference if your old clutch label shows a Warner 5219-series number.
Aftermarket Consolidation and Tolerance Notes
Aftermarket PTO clutch catalogs sometimes consolidate related OEM paths into one replacement clutch when the bore size, rotation, pulley alignment, belt tracking, deck-drive geometry, and mounting clearance are compatible within acceptable service tolerance.
For the Snapper / Murray 7063246YP path, the key checks are straightforward: confirm the 1 inch bore, counter-clockwise rotation, pulley alignment, connector style, and anti-rotation setup. If the old clutch has been replaced before, modified, or has unclear markings, compare the physical clutch layout before ordering.
Common Ordering Mistakes
- Ordering by mower brand alone: not every Snapper or Murray mower uses the same PTO clutch.
- Ignoring series numbers: Yard Cruiser, Scrambler, and Twin Stick applications can vary by series and deck setup.
- Confusing part-number paths: 7063246YP, 7063246, and 63246 are the main Snapper / Murray path. Broader Warner and aftermarket references should be checked carefully.
- Skipping pulley alignment checks: pulley diameter matters, but pulley position and belt tracking matter too.
- Replacing the clutch before checking the deck drive: a worn belt, seized idler, dragging spindle, weak ground, or melted connector can mimic clutch failure.
Before Installing the Replacement
Before installing a replacement PTO clutch, compare the new clutch to the old clutch and inspect the mower for issues that could damage the replacement.
- Confirm the original clutch number or parts lookup path when available
- Confirm 1 inch crankshaft bore
- Compare pulley diameter and pulley alignment
- Confirm counter-clockwise rotation from pulley side
- Compare wiring connector, wire lead, and anti-rotation setup
- Check the deck belt for glazing, cracking, stretching, oil contamination, or incorrect routing
- Spin idlers and spindle pulleys by hand to check for drag or bearing noise
- Inspect the crankshaft, key, bolt threads, and keyway for rust, burrs, or damage
Review the PTO clutch installation guide before mounting the replacement. If the old clutch is rusted, seized, binding on the keyway, or will not slide off the crankshaft by hand, use the PTO clutch stuck on crankshaft guide before forcing removal.
Need Help Confirming Fitment?
If you are not sure whether this clutch fits your Snapper or Murray mower, email support@ptodirectusa.com with your mower model number, serial number, deck size, engine package, and clear photos of the old clutch. For best fitment help, include photos of the clutch label or stamped number, wiring connector, pulley, anti-rotation setup, crankshaft area, and mower identification tag.
PTO Direct USA supplies aftermarket replacement PTO clutches for select Snapper ZTR, Murray, and related mower applications. These products are replacement parts for matching OEM and aftermarket cross-reference numbers. Confirm fitment before ordering.
Related PTO Clutch Cross-Reference Guides
- 7063246YP / 63246 PTO Clutch Cross Reference Guide
- Warner 5219 PTO Clutch Cross Reference
- Husqvarna 120786 / Dixon 16026 PTO Clutch Guide
- Country Clipper E-6317 PTO Clutch Guide
- John Deere AM138730 PTO Clutch Guide
FAQ
What PTO clutch replaces Snapper 7063246YP?
The 7063246YP PTO clutch replacement path is used on select Snapper ZTR Yard Cruiser, Scrambler, and Twin Stick applications when the original clutch number and physical specs match.
Does 7063246YP replace Snapper 63246?
Yes. 7063246YP, 7063246, and 63246 are part of the same Snapper / Murray PTO clutch replacement path on supported applications.
Does this fit Snapper ZTR Yard Cruiser models?
This path is commonly associated with select Snapper ZTR Yard Cruiser 42 inch and 48 inch Series 3 and Series 4 applications. Confirm your deck size, series, and clutch details before ordering.
Does this fit Snapper ZTR Scrambler models?
This path is commonly associated with select Snapper ZTR Scrambler 42 inch and 48 inch Series 5 and Series 6 applications. Confirm fitment before ordering.
Does this fit Snapper ZTR Twin Stick models?
This path is commonly associated with select Snapper ZTR Twin Stick 42 inch and 48 inch Series 6 applications. Confirm the clutch number and physical specs before ordering.
Does this replace Murray 63246?
Yes. Murray 63246, 7063246, and 7063246YP are commonly routed to this replacement path on supported applications.
What Warner number crosses to Snapper 7063246YP?
Warner 5219-15 is the key Warner cross-reference commonly associated with the Snapper 7063246YP / 63246 path.
What Xtreme numbers cross to this Snapper clutch?
Xtreme X0122, X0122-K, X0395, and X0395-K are commonly associated with the Snapper / Murray 7063246YP replacement path.
What bore size should I confirm?
This replacement path uses a 1 inch crankshaft bore.
What pulley size should I compare?
This replacement path is commonly listed in the 5.3 inch / 5.35 inch pulley class. Some catalogs round the pulley size differently, so compare pulley alignment and belt tracking before installation.
What rotation is this clutch?
This clutch path is listed as counter-clockwise rotation from the pulley side.
Can PTO Direct USA help identify my Snapper PTO clutch?
Yes. Email support@ptodirectusa.com with your mower model number, serial number, deck size, engine package, and photos of the old clutch, connector, pulley, anti-rotation setup, crankshaft area, and mower ID tag.
