Country Clipper E-6317 PTO Clutch Guide: Jazee, Trek, Wrangler & Zeton Brat

Country Clipper PTO clutch fitment is easiest when you start with the part number. If your original clutch, parts lookup, or cross-reference search points to E-6317, Warner 5219-22, or Xtreme X0347, you are likely in the Country Clipper E-6317 replacement path.

This guide helps route select Country Clipper Jazee, Country Clipper SR Series, Trek, Wrangler, and Zeton Brat applications to the correct aftermarket replacement PTO clutch path. PTO Direct USA routes this search path to the 7063246YP PTO Clutch Replacement when the mower setup, bore size, pulley alignment, wiring, rotation, and anti-rotation setup match.

Find Your Country Clipper E-6317 PTO Clutch Path

Table tip: On mobile, swipe sideways to view the full fitment table.

Important fitment note: This table is a routing guide, not a universal interchange guarantee. Country Clipper PTO clutch fitment can change by model year, engine package, deck size, wiring connector, pulley layout, anti-rotation setup, and previous repairs. Confirm fitment before ordering.

E-6317 PTO Clutch Replacement Path

The 7063246YP PTO Clutch Replacement is the lead aftermarket replacement path PTO Direct USA uses for Country Clipper E-6317 searches when the mower configuration and original clutch layout match.

• Country Clipper number: E-6317
• Warner search path: 5219-22
• Xtreme search path: X0347, X0347-K
• Common model path: select Jazee / Jazzee, SR Series, Trek, Wrangler, and Zeton Brat applications
• Crankshaft bore to confirm: 1 inch
• Rotation to confirm: Counter-clockwise from pulley side
• Critical checks: pulley position, belt alignment, connector style, wiring route, and anti-rotation setup

Country Clipper E-6317 fitment note: use the E-6317 number as a strong routing clue, but do not order by part number alone if the original clutch has been replaced before, modified, or has unclear markings. Compare pulley position, belt alignment, wiring connector, wire routing, and anti-rotation setup before installing the replacement.

Aftermarket Consolidation and Fitment Tolerance

Aftermarket PTO clutch catalogs may consolidate related OEM paths into one replacement clutch when the bore size, rotation, mounting clearance, belt alignment, and deck-drive geometry are compatible within acceptable service tolerance. That can be useful when older Country Clipper clutch numbers become hard to source.

For E-6317 searches, wiring route and anti-rotation setup matter. Before installation, line up the new clutch with the old clutch and confirm the belt rides correctly, the pulley does not rub, the anti-rotation stop sits correctly, and the wiring can route safely away from moving parts.

Country Clipper Jazee / Jazzee E-6317 Notes

The Country Clipper Jazee / Jazzee path is commonly associated with E-6317, Warner 5219-22, and Xtreme X0347 clutch searches. References may include 2004, 2005, II 2004, and II 2005 applications.

• Model path: Jazee / Jazzee
• Year references: 2004, 2005, II 2004, II 2005
• Common clutch number: E-6317
• Replacement path: 7063246YP PTO Clutch Replacement

Confirm the original clutch number, pulley alignment, wiring connector, and anti-rotation setup before ordering.

Country Clipper SR Series E-6317 Notes

The Country Clipper SR Series appears across a wide range of E-6317 PTO clutch searches. Because SR models can vary by year, horsepower, and engine package, use the model number and original clutch number together before choosing a replacement.

• SR100
• SR105
• ST110
• SR200
• SR205
• SR210
• SR215
• SR220
• SR300
• SR350
• SR360
• SR365
• SR370

SR Series fitment note: some SR references include different year and engine-package details. Confirm the old clutch number, mower model tag, deck setup, pulley alignment, wiring route, and anti-rotation setup before ordering.

Country Clipper Trek, Wrangler and Zeton Brat Notes

Country Clipper Trek, Wrangler, and Zeton Brat searches can also route through the E-6317 clutch path when the original clutch number and physical specs match.

• Trek: all models listed in this path
• Wrangler: 2011 reference
• Zeton Brat: verify by model and clutch number

If your Trek, Wrangler, or Zeton Brat application points to E-6317, compare the replacement clutch specs and physical layout before ordering.

Warner and Xtreme Cross-Reference Numbers

Some Country Clipper owners find a Warner or Xtreme number on the original clutch instead of the Country Clipper E-6317 number. These numbers can help route the replacement path.

• Country Clipper: E-6317
• Warner: 5219-22
• Xtreme: X0347, X0347-K

Cross-reference note: Warner and Xtreme numbers are routing clues, not mower model numbers. Use them together with the mower model, deck size, engine package, bore size, pulley alignment, wiring connector, and anti-rotation setup.

If your old clutch label shows a Warner 5219-series number, use the Warner 5219 PTO Clutch Cross Reference to compare Warner 5219-22, 5219-15, 5219-28, and related clutch paths.

How E-6317 Relates to the 7063246YP Cross-Reference Web

E-6317 often appears in broad PTO clutch cross-reference data alongside Snapper 7063246YP, Murray 63246, Husqvarna 120786, Warner 5219 numbers, Xtreme replacement paths, and other aftermarket references. That does not mean every mower in those groups uses the same original clutch geometry.

Use the 7063246YP PTO Clutch Cross Reference Guide to understand the broader replacement web, including Snapper, Murray, Husqvarna, Dixon, John Deere, Warner, Xtreme, and Country Clipper search paths.

Common E-6317 Ordering Mistakes

• Ordering by Country Clipper brand alone: not every Country Clipper mower uses the same PTO clutch.
• Ignoring model and year references: Jazee, SR Series, Trek, Wrangler, and Zeton Brat applications can vary by setup.
• Skipping wiring-route checks: Country Clipper layouts may require careful wire routing away from moving parts.
• Ignoring anti-rotation setup: the stop or bracket position must match the mower layout.
• Trusting long marketplace dumps without checking specs: cross-reference lists can lump related but different clutch paths together.
• Replacing the clutch before checking the deck drive: a worn belt, seized idler, dragging spindle, weak ground, or damaged connector can mimic clutch failure.

Before Installing an E-6317 Replacement Clutch

Before installing the replacement PTO clutch, compare the new clutch to the old clutch and inspect the mower for problems that could damage the replacement.

• Confirm the mower model, year reference, and deck size
• Confirm the original clutch number or parts lookup path when available
• Confirm 1 inch crankshaft bore
• Compare pulley diameter, pulley position, and belt alignment
• Confirm rotation from the pulley side
• Compare wiring connector, wire lead length, and routing
• Compare anti-rotation stop or bracket position
• Inspect the deck belt for glazing, cracking, stretching, oil contamination, or incorrect routing
• Spin idlers and spindle pulleys by hand to check for drag or bearing noise
• Inspect the crankshaft, key, bolt threads, and keyway for rust, burrs, or damage

Review the PTO clutch installation guide before mounting the replacement. If the old clutch is rusted, seized, binding on the keyway, or will not slide off the crankshaft by hand, use the PTO clutch stuck on crankshaft guide before forcing removal.

Need Help Confirming Fitment?

If you are not sure whether this clutch fits your Country Clipper mower, email support@ptodirectusa.com with your mower model number, serial number, deck size, engine package, and clear photos of the old clutch. For best fitment help, include photos of the clutch label or stamped number, wiring connector, pulley, anti-rotation setup, crankshaft area, and mower identification tag.

PTO Direct USA supplies aftermarket replacement PTO clutches for select Country Clipper, Snapper, Murray, Husqvarna, Dixon, AYP, Craftsman, John Deere, and related mower applications. These products are replacement parts for matching OEM and aftermarket cross-reference numbers. Confirm fitment before ordering.

Related PTO Clutch Cross-Reference Guides

• 7063246YP / 63246 PTO Clutch Cross Reference Guide
• Warner 5219 PTO Clutch Cross Reference
• Snapper 7063246YP / 63246 PTO Clutch Guide
• Husqvarna 120786 / Dixon 16026 PTO Clutch Guide
• John Deere AM138730 PTO Clutch Guide

FAQ

What PTO clutch replaces Country Clipper E-6317?

PTO Direct USA routes E-6317 searches to the 7063246YP PTO clutch replacement path when the mower configuration, bore size, pulley alignment, wiring, rotation, and anti-rotation setup match.

Does E-6317 cross to Warner 5219-22?

Yes. Warner 5219-22 is commonly associated with the Country Clipper E-6317 search path. Use it as a routing clue and confirm the full mower setup before ordering.

Does E-6317 cross to Xtreme X0347?

Xtreme X0347 and X0347-K are commonly associated with the E-6317 / Warner 5219-22 search path. Confirm physical fitment before ordering.

Does this fit Country Clipper Jazee or Jazzee models?

This path is commonly associated with select Country Clipper Jazee / Jazzee applications, including 2004, 2005, II 2004, and II 2005 references. Confirm the original clutch number and physical clutch layout before ordering.

Does this fit Country Clipper SR Series models?

This path is commonly associated with select SR Series references including SR100, SR105, SR200, SR205, SR210, SR215, SR220, SR300, SR350, SR360, SR365, and SR370. Confirm model, year, engine package, and clutch details before ordering.

Does this fit Country Clipper Trek?

Trek all models are commonly listed in the E-6317 search path. Confirm the original clutch number, deck setup, pulley alignment, wiring, and anti-rotation setup before ordering.

Does this fit Country Clipper Wrangler?

Wrangler 2011 is commonly listed in the E-6317 path. Confirm fitment before ordering.

Does this fit Zeton Brat?

Zeton Brat appears in the E-6317 search path. Confirm the mower model, original clutch number, bore size, pulley alignment, wiring connector, and anti-rotation setup before ordering.

What bore size should I confirm?

Confirm that your E-6317 clutch path uses a 1 inch crankshaft bore.

What pulley details matter most?

Do not look only at pulley diameter. Compare pulley position, belt alignment, belt tracking, clearance, and anti-rotation setup before installation.

Can PTO Direct USA help identify my Country Clipper PTO clutch?

Yes. Email support@ptodirectusa.com with your mower model number, serial number, deck size, engine package, and photos of the old clutch, connector, pulley, anti-rotation setup, crankshaft area, and mower ID tag.
