Warner 5219 PTO Clutch Cross Reference: 5219-15, 5219-22, 5219-28 & More

Warner 5219 PTO clutch numbers show up on clutch labels, parts diagrams, aftermarket listings, and cross-reference charts. The hard part is that not every Warner 5219 number automatically routes to the same original mower setup.

This guide is built to help you route common Warner 5219-series numbers including 5219-15, 5219-22, 5219-28, 5219-80, 5219-102, and 5219-48. PTO Direct USA routes many of these searches toward the 7063246YP PTO Clutch Replacement when the mower setup, bore size, pulley alignment, rotation, wiring, and anti-rotation setup match.

Find Your Warner 5219 PTO Clutch Path

Table tip: On mobile, swipe sideways to view the full cross-reference table.

Important fitment note: This table is a cross-reference routing guide, not a universal interchange guarantee. Warner numbers are useful clues, but final fitment depends on mower model, serial number, deck size, crankshaft bore, pulley alignment, wiring connector, and anti-rotation setup.

Have a mower-brand number instead of a Warner number? Use the focused guides below to narrow the path by OEM number, mower family, or model group:

• Snapper 7063246YP / 63246 PTO Clutch Guide for Snapper, Murray, Yard Cruiser, Scrambler, and Twin Stick paths.
• Husqvarna 120786 / Dixon 16026 PTO Clutch Guide for Husqvarna, AYP, Dixon, Craftsman, Poulan, Roper, and Yazoo Kees paths.
• John Deere AM138730 PTO Clutch Guide for Z225, Z425, Z445, Z465, and pulley-alignment checks.
• Country Clipper E-6317 PTO Clutch Guide for Jazee, SR Series, Trek, Wrangler, Zeton Brat, and Warner 5219-22 paths.

Why Warner 5219 Numbers Get Confusing

Warner 5219-series numbers are often grouped together in aftermarket catalogs because many of them share broad physical traits such as a 1 inch bore and counter-clockwise rotation. That does not mean every original clutch was built for the same mower, pulley layout, torque load, wiring route, or anti-rotation bracket.

For this reason, use the Warner number as a starting point, then verify the complete clutch path. The safest checks are the original mower brand number, mower model and serial number, deck size, bore size, pulley alignment, connector style, and anti-rotation setup.

Aftermarket Consolidation and Tolerance Notes

Aftermarket PTO clutch suppliers may consolidate related OEM paths into one replacement clutch when the bore size, rotation, mounting clearance, belt alignment, and deck-drive geometry are compatible within acceptable service tolerance. This can help keep older mowers serviceable when original clutch numbers become hard to source.

That does not mean every Warner 5219 number should be treated casually. If your original clutch has an offset-style pulley, unusual wire lead, special anti-rotation stop, previous aftermarket substitution, or unclear markings, compare the replacement clutch to the original before installation.

Warner 5219-15 Replacement Path

Warner 5219-15 is the cleanest and strongest Warner number in this cross-reference group. It is commonly connected to the Snapper / Murray 7063246YP, 7063246, and 63246 path, plus Husqvarna / AYP / Dixon numbers such as 120786, 539120786, and 16026.

• Warner number: 5219-15
• Common Snapper / Murray numbers: 7063246YP, 7063246, 63246
• Common Husqvarna / AYP / Dixon numbers: 120786, 539120786, 16026
• Lead replacement path: 7063246YP PTO Clutch Replacement

For Snapper-specific model routing, see the Snapper 7063246YP PTO Clutch Guide. For Husqvarna and Dixon routing, see the Husqvarna 120786 / Dixon 16026 PTO Clutch Guide.

Warner 5219-22 and Country Clipper E-6317 Path

Warner 5219-22 is commonly associated with the Country Clipper E-6317 path. This search family may include Country Clipper Jazee / Jazzee, SR Series, Trek, Wrangler, and Zeton Brat references.

• Warner number: 5219-22
• Country Clipper number: E-6317
• Common model clues: Jazee / Jazzee, SR Series, Trek, Wrangler, Zeton Brat
• Critical checks: wiring route, pulley position, anti-rotation setup, engine package, and deck-drive geometry

If your clutch label shows Warner 5219-22 or your parts lookup points to E-6317, compare the original clutch carefully before ordering.

For model-focused routing, use the Country Clipper E-6317 PTO Clutch Guide. It covers Jazee / Jazzee, SR Series, Trek, Wrangler, Zeton Brat, Warner 5219-22, and Xtreme X0347 search paths.

Warner 5219-28, 5219-80 and 5219-102 Path

Warner 5219-28, 5219-80, and 5219-102 often appear together in aftermarket cross-reference lists. These numbers may be tied to 114595, 539114595, 16138, and 50055658 search paths.

• Warner numbers: 5219-28, 5219-80, 5219-102
• Common OEM search paths: 114595, 539114595, 16138, 50055658
• Common brand clues: Dixon, Husqvarna, AYP, Bush Hog and related applications
• Critical checks: torque demand, pulley alignment, belt tracking, wiring, and anti-rotation setup

Because these numbers are often lumped into broad marketplace listings, use them as routing clues. Confirm your mower model, original clutch number, deck setup, and physical clutch details before ordering.

Warner 5219-48 Path

Warner 5219-48 may appear in broad Warner 5219 cross-reference data. If this is the number found on your old clutch, do not assume it automatically shares every detail with 5219-15, 5219-22, or 5219-28.

• Warner number: 5219-48
• Use case: cross-reference routing when the mower-brand number is unclear
• Critical checks: bore size, pulley class, pulley alignment, connector, wire lead, and anti-rotation setup

If the original mower-brand number is missing, send clear photos to PTO Direct USA before ordering so the clutch path can be checked more carefully.

Warner 5219-88 / 5219-225 and John Deere AM138730

Some John Deere AM138730 searches connect to Warner 5219-88 or 5219-225 references. This is a more sensitive path because John Deere EZtrak applications can have serial-range splits and offset-style pulley geometry.

• Warner search paths: 5219-88, 5219-225
• John Deere numbers: AM138730, AM136787, AM137323
• Common model clues: EZtrak Z225, Z425, Z445, Z465
• Critical checks: serial range, pulley position, belt alignment, wiring connector, and anti-rotation setup

For John Deere-specific routing, use the John Deere AM138730 PTO Clutch Guide.

Core Specs to Confirm

Pulley note: pulley size may be rounded differently across aftermarket catalogs. A clutch listed as 5.3 inch, 5.35 inch, or 5-3/8 inch may be referring to the same general pulley class, but pulley alignment and belt tracking still need to be confirmed on the mower.

How Warner Numbers Relate to the 7063246YP Cross-Reference Web

The Warner 5219 family overlaps with the broader 7063246YP PTO Clutch Cross Reference Guide. That master guide routes Snapper 7063246YP, Murray 63246, Husqvarna 120786, Dixon 16026, John Deere AM138730, Country Clipper E-6317, Bush Hog 50055658, Xtreme, Prime Line, and other related search paths.

If your Warner number is not enough to confirm fitment, start with the master cross-reference guide, then narrow by mower brand or model family.

Common Warner 5219 Ordering Mistakes

• Assuming all Warner 5219 numbers are identical: 5219-series numbers can share broad traits while still using different pulley positions, wiring, torque ratings, or mower-specific layouts.
• Ordering by Warner number alone: the mower brand number and model path still matter.
• Ignoring pulley alignment: pulley diameter matters, but pulley position and belt tracking matter just as much.
• Missing John Deere serial splits: AM138730 searches can involve serial-range and pulley-geometry traps.
• Ignoring wiring and anti-rotation setup: connector style, wire routing, and anti-rotation stop position must match the mower setup.
• Replacing the clutch before checking the deck drive: a worn belt, seized idler, dragging spindle, poor ground, or melted connector can mimic clutch failure.

Before Installing a Warner 5219 Replacement Clutch

Before installing a replacement PTO clutch, compare the new clutch to the old clutch and inspect the mower for issues that could damage the replacement.

• Confirm the Warner number and mower-brand number when available
• Confirm the mower model, serial number, deck size, and engine package
• Confirm crankshaft bore
• Compare pulley diameter, pulley position, and belt alignment
• Confirm rotation from the pulley side
• Compare wiring connector, wire lead, and routing
• Compare anti-rotation stop or bracket position
• Check the deck belt for glazing, cracking, stretching, oil contamination, or incorrect routing
• Spin idlers and spindle pulleys by hand to check for drag or bearing noise
• Inspect the crankshaft, key, bolt threads, and keyway for rust, burrs, or damage

Review the PTO clutch installation guide before mounting the replacement. If the old clutch is rusted, seized, binding on the keyway, or will not slide off the crankshaft by hand, use the PTO clutch stuck on crankshaft guide before forcing removal.

Need Help Confirming Fitment?

If you are not sure which Warner 5219 clutch path fits your mower, email support@ptodirectusa.com with your mower model number, serial number, deck size, engine package, and clear photos of the old clutch. For best fitment help, include photos of the Warner label or stamped number, mower-brand part number, wiring connector, pulley, anti-rotation setup, crankshaft area, and mower identification tag.

PTO Direct USA supplies aftermarket replacement PTO clutches for select Snapper, Murray, Husqvarna, Dixon, AYP, Craftsman, John Deere, Country Clipper, Bush Hog, Case, Jacobsen, and related mower applications. These products are replacement parts for matching OEM and aftermarket cross-reference numbers. Confirm fitment before ordering.

Related PTO Clutch Cross-Reference Guides

• 7063246YP / 63246 PTO Clutch Cross Reference Guide
• Snapper 7063246YP / 63246 PTO Clutch Guide
• Husqvarna 120786 / Dixon 16026 PTO Clutch Guide
• John Deere AM138730 PTO Clutch Guide
• Country Clipper E-6317 PTO Clutch Guide

FAQ

Are all Warner 5219 PTO clutches the same?

No. Warner 5219-series numbers can share broad traits such as bore size or rotation, but they may differ by pulley position, torque demand, wiring, anti-rotation setup, and mower application. Use the Warner number as a routing clue, then confirm the full mower setup.

What does Warner 5219-15 replace?

Warner 5219-15 commonly routes with Snapper 7063246YP, Snapper 7063246, Snapper 63246, Husqvarna 120786, Husqvarna 539120786, and Dixon 16026 on supported applications.

Does Warner 5219-15 cross to Snapper 7063246YP?

Yes. Warner 5219-15 is commonly associated with the Snapper / Murray 7063246YP / 63246 replacement path on supported applications.

Does Warner 5219-15 cross to Husqvarna 120786?

Yes. Warner 5219-15 is commonly associated with the Husqvarna / AYP / Dixon 120786 and 539120786 path on supported applications.

What is Warner 5219-22?

Warner 5219-22 is commonly associated with the Country Clipper E-6317 search path. Confirm wiring, pulley position, anti-rotation setup, model, and deck-drive geometry before ordering.

What are Warner 5219-28, 5219-80 and 5219-102?

These Warner numbers often appear in related aftermarket cross-reference lists and may be associated with 114595, 539114595, 16138, and 50055658 search paths. Confirm the original clutch layout before ordering.

Does Warner 5219-88 or 5219-225 cross to John Deere AM138730?

Warner 5219-88 and 5219-225 are commonly connected to John Deere AM138730 / AM136787 / AM137323 search paths. Confirm model, serial range, pulley alignment, wiring, and anti-rotation setup before ordering.

Can I order by the Warner number only?

A Warner number is a strong starting point, but final fitment should still be confirmed by mower model, serial number, deck size, engine package, bore size, pulley alignment, connector, and anti-rotation setup.

What pulley size should I compare?

The 7063246YP / 63246 path is commonly listed in the 5.3 inch / 5.35 inch pulley class. Other Warner 5219 paths may vary, so compare pulley position and belt tracking before installation.

Can PTO Direct USA help identify my Warner PTO clutch?

Yes. Email support@ptodirectusa.com with your mower model number, serial number, deck size, engine package, and photos of the old clutch label, connector, pulley, anti-rotation setup, crankshaft area, and mower ID tag.
