Many Cub Cadet PTO clutch searches start with a part number instead of a mower model. You may have a stamped number like 917-05209, 717-04552A, Warner 5219-98, 01008434, or Stens 255-668X and need to know which replacement path it belongs to.
This guide routes common Cub Cadet, MTD, Warner, Ogura, Stens, Xtreme, Oregon, Rotary, and Prime Line numbers to the correct aftermarket replacement PTO clutch path. Use the searched number as your starting point, then confirm the lead product page specs before ordering.
Cub Cadet PTO Clutch Cross-Reference Finder
Table tip: On mobile, swipe sideways to view the full fitment table.
| Searched Number | Related OEM / Cross-Reference Numbers | Lead Replacement Path | Common Routing Use | Shop Replacement |
|---|---|---|---|---|
| 917-05209 | 717-05209, Warner 5219-177, Xtreme X0726, Xtreme X0736, Stens 255-668X, Rotary 16173, Sunbelt B1XT0726 | 917-05209 | XT1, XT2, RZT-L, RZT-S, ZT1, ZT2 and select MTD-built applications | Shop 917-05209 PTO Clutch |
| 917-04552A | 717-04552A, 917-04552, 717-04552, Warner 5219-98, Xtreme X0390, Stens 255-839X, Rotary 14229, Sunbelt B1XT0390 | 917-04552A | RZT 50, RZT 54, LTX1050 and select Cub Cadet / MTD applications | Shop 917-04552A PTO Clutch |
| 917-04526A | 717-04526A, 917-04526, 717-04526, Warner 5219-94, Xtreme X0387, Stens 255-225X | 917-04526A | i1042, ZTT42 and select 42-inch Cub Cadet applications | Shop 917-04526A PTO Clutch |
| 917-05001 | 717-05001, 917-1774C, 717-1774C, Warner 5219-25, Stens 255-297X, Oregon 33-104, Prime Line 7-06298 | 917-05001 | GT1554, SLT1554 and select Cub Cadet lawn tractor applications | Shop 917-05001 PTO Clutch |
| 917-04967 | 717-04967, Warner 5218-288, Xtreme X0400, Xtreme X0275, Stens 255-622X | 917-04967 | Tank LZ, Tank SZ, Pro Z and select commercial Cub Cadet applications | Shop 917-04967 PTO Clutch |
| 917-04754A | 717-04754A, 917-04754, 717-04754, Warner 5219-119, Ogura 01009590, Ogura 01009590P, Xtreme X0505, Oregon 274-2407 | 917-04754A | Z-Force S steering-wheel zero-turn applications | Shop 917-04754A PTO Clutch |
| 917-1709 | 717-1709, 1706692SM, Warner 5215-130, Warner 5215-22, Oregon 33-126-1, Oregon 33-139, Stens X0423 | 917-1709 | RZT 42, RZT 50, Tank, Z-Force and select MTD-built applications | Shop 917-1709 PTO Clutch |
| 01008434 | 759-05064, 01008434P, 539124833, 124833, 3579, Xtreme X0707, Stens 255-371X, 8TEN 810-CPT2303O | 759-05064 / 01008434 | Z-Force, Z-Force Pro, Enforcer, Tank M50 and select commercial crossover applications | Shop 759-05064 PTO Clutch |
| 01008544P | 01008544, 917-04127, 717-04127, 01009268P, 01009268, Stens 255-910X | 01008544P | RZT, Z-Force, Tank M48-HN, Troy-Bilt and MTD-built applications | Shop 01008544P PTO Clutch |
| 917-04622 | 717-04622, 917-04183, 717-04183, Warner 5219-99 | 917-04622 | RZT42, RZT50, LX1050, Troy-Bilt Mustang XP and MTD-built zero-turn applications | Shop 917-04622 PTO Clutch |
| 02002160P | 02002160, 2002160, Ogura MA-GT-KB05P, Ogura GT1-CT04, Stens 255-370X, Stens 255-795X | 02002160P | Enforcer 48, Enforcer 54, Z-Force 60 and select Cub Cadet zero-turn applications | Shop 02002160P PTO Clutch |
| TCA19812 | TCA21168, TCA20655, TCA16997, 917-05184, 717-05184, Warner 5219-84, Warner 5219-141, Warner 5219-44 | TCA19812 | Pro Z, Pro X, Tank and select commercial crossover applications | Shop TCA19812 PTO Clutch |
| 917-3403 | 717-3403, 917-04180, 717-04180, 717-3403P | 917-3403 | GT2500 and select Cub Cadet garden tractor applications | Shop 917-3403 PTO Clutch |
| 917-04080 | 717-04080 | 917-04080 | Cub Cadet, Craftsman, Huskee, MTD, Yard Machines and Yard-Man applications | Shop 917-04080 PTO Clutch |
| 917-04174 | 717-04174, 717-04174A, 746-04174A, 946-04174A | 917-04174 | Cub Cadet, Columbia, Yard-Machines and related MTD-built applications | Shop 917-04174 PTO Clutch |
| 917-05121 | 717-05121, 717-04376, 717-04376A, 917-04376, 917-04376A | 917-05121 | Troy-Bilt, Cub Cadet, Craftsman and select MTD-built 42-inch platforms | Shop 917-05121 PTO Clutch |
| 917-3044 | 717-3044, 917-3012, 717-3012, IH-144722-C91, IH-144720-C91 | 917-3044 | Cub Cadet garden tractors and International Harvester-built platforms | Shop 917-3044 PTO Clutch |
| 917-3340 | 717-3340 | 917-3340 | Cub Cadet garden and compact tractor applications | Shop 917-3340 PTO Clutch |
| 917-3385B | 917-3385, 917-3385A, 717-3385, 717-3385A | 917-3385B | Cub Cadet, Craftsman, MTD, Troy-Bilt, Bolens and Huskee applications | Shop 917-3385B PTO Clutch |
| 917-3389 | 717-3389, 717-3389P, 717-3375 | 917-3389 | Cub Cadet, MTD and White Outdoor mower applications | Shop 917-3389 PTO Clutch |
| IH-61313-C93 | IH-61313-C92 | IH-61313-C93 | International Harvester-built Cub Cadet tractor applications | Shop IH-61313-C93 PTO Clutch |
Important fitment note: This cross-reference index is a routing guide, not a universal interchange list. Part numbers are strong confirmation points, but final fitment can still depend on model year, serial number, deck size, engine package, and machine configuration. Before ordering, open the lead product page and compare the listed application notes and product details to your mower.
How to Use 917 and 717 Cub Cadet PTO Clutch Numbers
Many Cub Cadet and MTD PTO clutch numbers appear in both 917 and 717 formats. In many cases, the matching base number routes to the same replacement path. For example, 917-05209 and 717-05209 both route to the 917-05209 PTO clutch replacement path.
Suffixes still matter. A number ending in A, B, or another revision letter should be checked carefully against the lead product page. Do not drop the suffix unless the product page specifically lists both versions.
Common Number Routing Examples
917-05209 / 717-05209
917-05209 routes to the 917-05209 replacement path. This is a common Cub Cadet / MTD clutch family for select XT1, XT2, RZT-L, RZT-S, ZT1, and ZT2 applications. It also cross-references Warner 5219-177 and several aftermarket numbers.
917-04552A / 717-04552A
917-04552A routes to the 917-04552A replacement path. This family is commonly associated with select RZT 50, RZT 54, LTX1050, and related MTD-built applications using the Warner 5219-98 clutch path.
917-1709 / 717-1709
917-1709 routes to the 917-1709 replacement path. This path appears in searches for RZT 42, RZT 50, Tank, Z-Force, and select crossover applications. Confirm the mower configuration before treating it as a replacement for another RZT clutch family.
01008434 / 759-05064
01008434 routes to the 759-05064 / 01008434 replacement path. This is a common Cub Cadet / MTD commercial and crossover path for select Z-Force, Enforcer, Tank M50, and related applications. Keep this family separate from heavier 1-1/8" commercial paths such as 917-04967, TCA19812, and 02002160P.
01008544P / 917-04127 / 717-04127
01008544P routes to the 01008544P replacement path. This family also includes 01008544, 917-04127, 717-04127, 01009268P, and 01009268 on supported applications.
917-04967 / 717-04967
917-04967 routes to the 917-04967 replacement path. This is a heavier Cub Cadet commercial path used on select Tank LZ, Tank SZ, and Pro Z applications. It also cross-references Warner 5218-288, Xtreme X0400, Xtreme X0275, and Stens 255-622X.
TCA19812 / 917-05184 / 717-05184
TCA19812 routes to the TCA19812 replacement path. This commercial family can appear in Cub Cadet Pro Z, Pro X, Tank, and some multi-brand commercial mower searches. Because this number also appears outside Cub Cadet applications, confirm the mower platform before ordering.
What If Your Number Is Warner, Ogura, Stens, Xtreme or Oregon?
If your clutch is marked with a Warner, Ogura, Stens, Xtreme, Oregon, Rotary, Sunbelt, Prime Line, or 8TEN number, use it as a cross-reference into the lead replacement path. For example, Warner 5219-98 routes to the 917-04552A PTO clutch replacement path, while Warner 5219-177 routes to the 917-05209 PTO clutch replacement path.
Aftermarket numbers can consolidate multiple older clutch versions into one replacement family. That can be helpful, but it also means you should still verify the product page details before ordering.
If the Clutch Number Is Missing or Unreadable
If the original clutch number is missing, damaged, painted over, or unreadable, start with the mower model number, serial number, deck size, engine package, and machine configuration. Those details help narrow the correct clutch path before you compare the lead product page.
- RZT and residential zero-turn models: compare deck size, model year, and series name first.
- Tank, Pro Z, Z-Force and Enforcer models: compare commercial series, engine package, deck size, and serial range.
- XT1, XT2, LTX and GT tractors: compare lawn tractor series, deck size, and original clutch family.
- Older garden tractors and IH-era machines: compare tractor model, crankshaft size, pulley family, and legacy IH number when available.
If your mower blades will not engage and you are not sure the clutch is actually the failed part, start with the PTO clutch won’t engage troubleshooting guide before replacing parts.
Need Help Cross-Referencing a Cub Cadet PTO Clutch?
If you are not sure which Cub Cadet PTO clutch path your number belongs to, email support@ptodirectusa.com with the number you found, your mower model number, serial number, deck size, and clear photos of the clutch. For best results, include photos of the clutch label or stamped number, wiring connector, pulley, anti-rotation setup, crankshaft area, and mower identification tag.
PTO Direct USA supplies aftermarket replacement PTO clutches for select Cub Cadet, MTD-built, Troy-Bilt, Craftsman, Z-Force, RZT, Tank, Pro Z, and garden tractor applications. These products are replacement parts for matching OEM part numbers. Confirm fitment before ordering.
FAQ
Are Cub Cadet 917 and 717 PTO clutch numbers the same?
Often, yes. Many Cub Cadet / MTD clutch families appear in both 917 and 717 number formats. For example, 917-05209 and 717-05209 route to the same replacement path. Always keep suffix letters such as A or B attached when comparing numbers.
What does 917-05209 replace?
917-05209 commonly pairs with 717-05209 and Warner 5219-177. It also cross-references several aftermarket numbers including Xtreme X0726, Xtreme X0736, Stens 255-668X, Rotary 16173, and Sunbelt B1XT0726 on supported applications.
What does 917-04552A replace?
917-04552A commonly pairs with 717-04552A, 917-04552, 717-04552, and Warner 5219-98. It is commonly routed to select RZT 50, RZT 54, LTX1050, and related MTD-built applications.
What does 01008434 cross-reference to?
01008434 commonly routes with 759-05064, 01008434P, 539124833, 124833, 3579, Xtreme X0707, and Stens 255-371X. This path is commonly used on select Z-Force, Enforcer, Tank M50, and related applications.
What does 01008544P replace?
01008544P commonly pairs with 01008544, 917-04127, 717-04127, 01009268P, and 01009268. It is used on select Cub Cadet, Troy-Bilt, MTD, RZT, and Z-Force applications.
What does Warner 5219-177 cross to?
Warner 5219-177 routes to the Cub Cadet / MTD 917-05209 and 717-05209 replacement path on supported applications.
What does Warner 5219-98 cross to?
Warner 5219-98 routes to the Cub Cadet / MTD 917-04552A, 717-04552A, 917-04552, and 717-04552 replacement path on supported applications.
What does Warner 5218-288 cross to?
Warner 5218-288 routes to the Cub Cadet / MTD 917-04967 and 717-04967 replacement path on supported Tank, Pro Z, and commercial applications.
What are Warner PTO clutch numbers on Cub Cadet clutches?
Warner numbers such as 5219-177, 5219-98, 5219-119, and 5218-288 are manufacturer cross-reference numbers that can help identify the correct Cub Cadet replacement path. If you are trying to understand Warner clutch numbering or compare a Warner-marked clutch, see our Warner PTO clutch systems guide.
Can I order a Cub Cadet PTO clutch by part number only?
If the part number is clear and matches the lead product page, it is usually the strongest starting point. Still compare the product page details and application notes before ordering, especially if your mower has multiple deck, engine, or serial range variations.
Can PTO Direct USA help cross-reference my PTO clutch number?
Yes. Email support@ptodirectusa.com with the number you found, your mower model number, serial number, deck size, and photos of the clutch, connector, pulley, anti-rotation setup, crankshaft area, and mower ID tag.
