Find PTO clutch and deck parts references for the Hustler Super Z model 932145 with its 60-inch side-discharge deck. This guide covers the 606936K / 603336K clutch, blades, spindles, idlers and deck belt, with links to matching aftermarket listings.
Model 932145 at a Glance
| Model | Hustler 932145 |
|---|---|
| Factory series | Super Z HyperDrive |
| Deck | 60-inch side discharge |
| Factory engine | Kawasaki FX850, advertised 27 hp |
PTO Clutch Part Numbers
| Reference | Part number |
|---|---|
| Hustler clutch kit | 606936K / 603336K |
| Warner reference | 5228-87 |
| Xtreme reference | X0809 |
The Hustler Super Z HD parts manual lists 606936K in Pump Drive – Kawasaki, section 4-5, item 6. Xtreme's application catalog specifically includes 932145 with the 603336K / 606936K references.
Bore, Pulley and Mounting Reference
Warner publishes these specifications for 5228-87:
| Bore | 1-1/8 inch / 1.125 inches |
|---|---|
| Pulley outside diameter | 7.24 inches |
| Rotation | CW — clockwise |
| Mounting configuration | Reverse |
These are Warner reference specifications. Check the chosen replacement's own dimensions and ratings when comparing aftermarket options.
Aftermarket Clutch Option
View our 606936K / 603336K aftermarket PTO clutch for product photos, specifications and included components.
Clutch Fitment Checks
- Match the original number: Read the clutch label or check the parts diagram for your complete model and serial number.
- Compare the installation: Check bore, pulley diameter and offset, belt groove, connector and anti-rotation mounting.
- Use the correct model: A 60-inch deck or Super Z decal alone does not identify the clutch.
60-Inch Deck Parts
These references apply to the 60-inch side-discharge deck shown in sections 8-2 and 8-3 of the Hustler Super Z HD parts manual. Quantities below are per complete deck.
| Part / OEM reference | Quantity and listing |
|---|---|
|
Mower blades 602771 |
3 blades View 3-blade set |
|
Mulching blade option 794214 / 794214X |
3 blades View 3-pack mulching blades |
|
Spindle assemblies 607407 / 607407P / 604255 |
3 assemblies View 3 spindle assemblies |
|
Deck idler pulleys 602821 |
2 idlers View 602821 idler pulley |
Blade selection: Choose one matching three-blade set for a complete change. The manual lists 602771 as the main blade reference and 794214 as a mulching option; these are different cutting profiles.
Spindle selection: The linked option contains three spindle assemblies only. This deck's spindle pulley reference is 602745; the optional 770842 pulley bundles on that listing use a different reference.
Additional OEM Deck References
| Part / quantity | OEM reference |
|---|---|
| Deck drive belt — 1 | 604494 |
| Spindle drive pulleys — 3 | 602745 |
| Large deck idler — 1 | 602743 |
For help sourcing these parts or building a deck service package, send the OEM numbers and your mower's model and serial tag to the Parts Desk. Compare the installed deck if it has been replaced or modified.
Need Help Matching Your Parts?
Text your model and serial tag and photos of the parts you need to 541-361-8778. For clutch help, include its label and connector.
Open the Parts DeskFitment support before and after purchase.
Next: PTO clutch installation guide · More Hustler quick references
