Overview
If your original clutch is marked Bobcat 2721337, Bob-Cat 2721337, Bunton 2721337, or Warner 5218-213, this guide explains the correct replacement path and the most important fitment checks before ordering.
The 2721337 PTO clutch is the heavy-duty Bobcat clutch path used on select commercial zero-turn applications, including many higher-horsepower Bobcat ProCat, Bobcat Predator Pro, and ZT200-series machines. It is a 200 ft-lb clutch path and should not be confused with the lower-torque 2722016 / Warner 5219-14 path used on 19HP applications.
Do not order by appearance alone. Match the original clutch number first, then confirm engine horsepower, crankshaft bore, pulley diameter, belt width, rotation, connector style, pigtail setup, and anti-rotation bracket before ordering.
Bobcat 2721337 PTO Clutch Route
The Bobcat 2721337 route connects to the Warner commercial-duty clutch family.
- Bobcat / Bob-Cat: 2721337
- Bunton: 2721337
- Warner: 5218-213
- Legacy Warner References: 5218-65, 5218-65E
Key Specifications
| Specification | Bobcat 2721337 Path |
|---|---|
| Primary OEM Number | 2721337 |
| Warner Number | 5218-213 |
| Legacy Warner Numbers | 5218-65, 5218-65E |
| Crankshaft Bore | 1-1/8 inch |
| Pulley Diameter | 6-5/16 inch / approximately 6.31 inches |
| Belt Width | 5/8 inch belt |
| Rotation | CW from pulley side |
| Voltage | 12V DC |
| Torque Rating | 200 ft-lbs |
| Electrical Draw | Approximately 6.53 amps |
| Coil Resistance | Approximately 1.84 ohms |
| Connector Note | Uses external pigtail / harness routing on Bobcat applications |
Critical 19HP Fitment Warning
Stop before ordering: if your Bobcat mower has a 19HP engine, do not assume the 2721337 clutch is correct.
The 2721337 / Warner 5218-213 path is the heavy-duty 200 ft-lb route for many 20HP-and-higher Bobcat commercial applications. Bobcat 19HP applications commonly route to the lower-torque 2722016 / Warner 5219-14 clutch instead.
For a side-by-side breakdown, see the 2721337 vs 2722016 Guide.
Common Bobcat Applications
The 2721337 clutch path is used on select higher-horsepower Bobcat commercial mower applications. This is not a complete model list. Always confirm the original clutch number and engine horsepower before ordering.
Bobcat ZT200-Series Applications
- ZT200 Series: select 942203, 942204, and 942206 applications
- Bobcat 942223A: higher-horsepower applications only; does not fit 19HP variants
- Bobcat 218ES / 942211A: confirm original clutch number
- Bobcat 220ES / 942214A: confirm original clutch number
- Bobcat 226ES / 942212A: confirm original clutch number
- ZT220D, ZT225, ZT226ES, ZT227: select 20HP-and-higher applications
Bobcat ProCat Applications
- ProCat Series: select 52-inch and 61-inch commercial applications
- 942237F: 27HP Kohler path noted in research
- 942250F, 942251F, 942252F, 942253F: 22HP and 26HP Kawasaki paths noted in research
For model-family routing, see the ProCat Fitment Guide.
Bobcat Predator Pro Applications
- Predator Pro: select heavy-duty 61-inch and 72-inch commercial applications
- 942241F and 942242F: 33HP Generac paths noted in research
- 942257F and 942258F: 37HP Kawasaki DFI paths noted in research
- 942241E, 942242E, 942245E: select legacy production applications
For model-family routing, see the Predator Pro Fitment Guide.
Replaces and Cross-References
The 2721337 clutch route is commonly searched under Bobcat, Warner, Xtreme, Stens, Rotary, Oregon, Prime Line, Exmark, and Hustler numbers.
Primary Replacement Path
- Bobcat / Bob-Cat: 2721337
- Bunton: 2721337
- Warner: 5218-213
- Warner Legacy: 5218-65, 5218-65E
Aftermarket Cross-References
- Xtreme: X0049
- Stens: 255-552
- Rotary: 11237
- Oregon: 33-136
- Prime Line: 7-06278
Physical Cross-References With Wiring Caution
- Exmark: 103-0665, 1-641300
- Hustler: 787366, 787366K
Important wiring note: Exmark 103-0665 and Hustler 787366 may share the same physical clutch body family as the Bobcat 2721337 path, but harness length, connector style, pigtail routing, and polarity may vary by mower brand and model. Bobcat buyers should order by the Bobcat 2721337 path and verify the original pigtail setup before installation.
Buy the Correct PTO Clutch Replacement
If your original PTO clutch is marked 2721337, 5218-213, 5218-65, or 5218-65E, start by matching that number first. Then verify the 1-1/8 inch bore, 6-5/16 inch pulley, 5/8 inch belt, CW rotation (from pulley side), connector style, and engine horsepower before ordering.
Shop the 2721337 PTO Clutch Replacement
2720949 Pigtail and Wiring Check
Many Bobcat 2721337 applications use an external pigtail harness between the clutch and the mower wiring harness. The Bobcat pigtail commonly referenced with this clutch path is 2720949.
Before installing a new clutch, inspect the existing pigtail and wiring for:
- Melted insulation near the clutch
- Green corrosion inside terminals
- Loose or brittle connector housings
- Short or stretched wiring near the engine
- Previous splices or non-OEM repairs
- Low voltage at the clutch connector
A weak or damaged pigtail can reduce voltage to the clutch coil. That can make a new clutch slip, run hot, or fail early even when the clutch itself is correct.
Do Not Confuse With 2722016
The Bobcat 2722016 path is not just another label for 2721337. It is a different clutch route commonly tied to 19HP Bobcat applications and Warner 5219-14.
| Part Number | Warner Number | Torque | Typical Route |
|---|---|---|---|
| 2721337 | 5218-213 | 200 ft-lbs | Bobcat 20HP+ commercial applications |
| 2722016 | 5219-14 | 125 ft-lbs | Bobcat 19HP and lighter applications |
Because both paths can share similar bore and pulley dimensions, do not choose between them by appearance alone. Match the original clutch number and engine horsepower.
Do Not Confuse With Bobcat 2721110
Do not confuse the 2721337 path with Bobcat 2721110. The 2721110 path is a different clutch used on different Bobcat applications.
- 2721337: 1-1/8 inch bore, 6-5/16 inch pulley, CW rotation
- 2721110: 1-inch bore, larger 7-inch class pulley, CCW rotation
If your original clutch uses a 1-inch bore or counter-clockwise rotation, this 2721337 path is not the correct replacement.
Common Symptoms of PTO Clutch Failure
- Mower blades will not engage
- PTO switch clicks but blades do not spin
- Blades engage cold but stop after the mower heats up
- Clutch slips under heavy deck load
- Burning smell near the clutch or belt
- Fuse blows when the PTO is engaged
- Connector or pigtail is melted near the clutch
- Deck belt smokes, jumps, or loses tension
- Grinding, squealing, or bearing noise below the engine
Before Ordering
Before ordering a Bobcat 2721337 replacement, confirm:
- Original clutch number stamped on the clutch or label
- Mower brand, model number, and serial number
- Engine horsepower, especially whether the mower is a 19HP variant
- 1-1/8 inch crankshaft bore
- 6-5/16 inch pulley diameter
- 5/8 inch belt width
- CW rotation from pulley side
- External pigtail / connector style
- Condition of the 2720949-style pigtail harness, if equipped
- Anti-rotation bracket or clutch stop setup
- Deck belt path and pulley alignment
- Condition of idlers, spindle bearings, battery, PTO switch, and wiring
Installation Notes
A correct clutch can fail early if the installation or surrounding mower system is wrong.
- Clean the crankshaft before installing the replacement clutch.
- Inspect the keyway and replace a worn or damaged woodruff key.
- Do not force the clutch over a mushroomed key or burred crankshaft.
- Do not tighten the center bolt with an impact wrench.
- Use a torque wrench and follow the engine manufacturer's crankshaft bolt specification.
- Inspect the clutch stop or anti-rotation bracket before startup.
- Check battery voltage and PTO switch output at the clutch connector.
- Burnish the clutch before mowing under load.
For burnishing, engage and disengage the PTO several times at reduced engine speed without cutting grass. This helps the rotor and armature friction surfaces seat properly before the clutch is placed under full mowing load.
Related Bobcat Guides
- Bobcat Fitment Guide
- Warner 5218-213 Guide
- 2721337 vs 2722016 Guide
- ProCat Fitment Guide
- Predator Pro Fitment Guide
FAQ
What PTO clutch replaces Bobcat 2721337?
The Bobcat 2721337 path commonly cross-references to Warner 5218-213, Warner 5218-65, Warner 5218-65E, Xtreme X0049, Stens 255-552, Rotary 11237, Oregon 33-136, and Prime Line 7-06278.
Is Warner 5218-213 the same path as Bobcat 2721337?
Yes. Warner 5218-213 is the primary Warner number associated with the Bobcat 2721337 heavy-duty clutch path.
Does Bobcat 2721337 replace Warner 5218-65?
Yes. Warner 5218-65 and 5218-65E are legacy Warner references that route to the 2721337 / 5218-213 clutch path.
Does this fit Bobcat 942223A?
This clutch is listed for Bobcat 942223A applications that use the 2721337 path, but it does not fit 19HP variants. Verify your engine horsepower and original clutch number before ordering.
Does this fit Bobcat 19HP models?
No. Bobcat 19HP applications commonly require the 2722016 / Warner 5219-14 clutch path instead. Do not order 2721337 for a 19HP Bobcat application unless your original clutch number clearly confirms it.
What is the difference between 2721337 and 2722016?
The 2721337 path is a 200 ft-lb heavy-duty clutch commonly used on 20HP-and-higher Bobcat commercial applications. The 2722016 path is a 125 ft-lb clutch commonly used on 19HP and lighter applications. They are not interchangeable just because the bore and pulley size may look similar.
What pigtail is associated with Bobcat 2721337?
Bobcat 2721337 applications commonly reference the 2720949 pigtail harness. Inspect your existing pigtail for heat damage, corrosion, broken terminals, or previous repairs before installing the replacement clutch.
Does this replace Exmark 103-0665 or Hustler 787366?
The Bobcat 2721337 path shares a physical clutch family with Exmark 103-0665 and Hustler 787366, but wiring harnesses and pigtail setups can vary by brand and model. Bobcat buyers should match the Bobcat clutch number and verify the pigtail before ordering.
Is this the same as Bobcat 2721110?
No. Bobcat 2721110 is a different clutch path with different bore, pulley, and rotation requirements. Do not substitute 2721337 for 2721110.
Where can I buy the 2721337 PTO clutch replacement?
Shop the 2721337 PTO Clutch Replacement.
Need help confirming Bobcat fitment? Contact PTO Direct USA with your mower model number, serial number, engine horsepower, deck size, original clutch number, and clear photos of the clutch label, pulley, wiring connector, pigtail, anti-rotation bracket, and mower ID tag before ordering.
