Use this John Deere PTO clutch cross-reference index to match old OEM numbers, superseded part numbers, Warner numbers, Ogura numbers, Stens numbers, Xtreme numbers, Oregon numbers, Rotary numbers, and 8TEN numbers to the correct PTO Direct USA lead product path.
Each row below is organized around one rule: this searched number belongs to this lead product path. The lead part number is the product page that should receive the search, the click, and the final fitment check.
Important fitment note: This index is a routing guide, not a universal interchange list. PTO clutch fitment can change by model year, serial number, deck size, and machine configuration. If the original clutch part number is missing or unreadable, verify the lead product page specs before ordering, including crankshaft bore, pulley diameter, rotation, and connector plug.
If you are unsure which clutch fits your mower, compare your original clutch number, mower model, serial number, pulley size, crankshaft bore, connector style, and deck belt path before installation. You can also review the PTO Direct USA fitment guarantee.
John Deere Commercial ZTrak PTO Clutch Cross-Reference
These are the highest-risk John Deere cross-reference paths because many ZTrak models change by serial number, deck size, or clutch family. Do not assume every ZTrak clutch is interchangeable.
Table tip: Scroll sideways on mobile to view the full cross-reference table.
| Searched Part Number | Lead Product Path | Replaces / Cross-References | Main Platform | Critical Fitment Note | Product Link |
|---|---|---|---|---|---|
|
TCA16998 Warner 5218-245 Warner 5218-157 Xtreme X0259 Stens 255-153 |
TCA19813 | John Deere TCA19813, TCA16998, Warner 5218-245, Warner 5218-157, Xtreme X0259, X0259-K, Stens 255-153, Stens 255-153X, Oregon 33-276, Rotary 15207, 8TEN 810-CPT2366O | John Deere ZTrak commercial mowers | Early serial path. Used on select Z720A, Z910A, and Z920A applications up to serial number 020000. Also used on select Z810A, Z820A, and Z520A 60-inch paths. Do not merge with TCA21167 or TCA21168. | View TCA19813 clutch |
|
TCA20604 Warner 5218-271 Warner 5218-401 Xtreme X0269 Stens 255-155 |
TCA21167 | John Deere TCA21167, TCA20604, Warner 5218-271, Warner 5218-401, Xtreme X0269, X0269-K, Stens 255-155, Stens 255-155X, Oregon 33-277, 8TEN 810-CPT2376O | John Deere ZTrak commercial mowers | Late serial path. Used on Z720A serial number 020001 and higher. Also used on select Z910A, Z920A, and Z925A applications by serial number and deck size. Do not use for Z710A. | View TCA21167 clutch |
|
TCA19812 TCA20655 Warner 5218-157 Xtreme X0223 Stens 255-039X |
TCA21168 | John Deere TCA21168, TCA20655, TCA19812, Warner 5218-157, Xtreme X0223, Stens 255-039X | John Deere Z510A, Z520A, Z710A | 6.3-inch pulley path. Fits Z510A, Z520A, and Z710A serial number 020001 and higher. Do not merge with TCA19813, TCA21167, Cub Cadet 917-05184, or 7.2-inch pulley clutch paths. | View TCA21168 clutch |
|
TCA16999 TCA19141 Warner 5228-3 |
TCA20380 | John Deere TCA20380, TCA16999, TCA19141, Warner 5228-3 | John Deere Z820A 60-inch deck path | Used for the Z820A 60-inch deck path. Do not merge with TCA19813, which covers different Z820A deck applications. | View TCA20380 clutch |
|
TCA12522 Warner 5218-91 Warner 5218-73 Warner 5218-225 Warner 5218-307 |
TCA12522 | Warner 5218-91, 5218-73, 5218-225, 5218-307, Oregon 33-188, Stens 255-871X | John Deere ZTrak 737, 757, 777, 797 | Commercial ZTrak path. Confirm original clutch number, bore, pulley, connector, and anti-rotation setup before ordering. | View TCA12522 clutch |
| TCA14535 | TCA14535 | John Deere TCA14535 | John Deere ZTrak 717, 727 | Use this path only when the original clutch or parts lookup confirms TCA14535. | View TCA14535 clutch |
|
GDA10017 Warner 5219-4 Warner 5219-58 Warner 5219-66 Warner 5219-222 |
GDA10017 | GDA10017, Warner 5219-4, 5219-58, 5219-66, 5219-222, Stens 255-146, 8TEN 810-CPT2342O | John Deere 647, 657, 667, 717, 727 and related commercial walk-behind / Quik-Trak paths | Commercial walk-behind and Quik-Trak style path. Verify machine model, original clutch number, and connector before ordering. | View GDA10017 clutch |
|
TCA23182 Warner 5218-385 |
TCA23182 | John Deere TCA23182, Warner 5218-385, Xtreme X0437 | John Deere Quik-Trak 648R, 652R, 661R | Quik-Trak path. Confirm original clutch number and physical mounting profile before ordering. | View TCA23182 clutch |
|
TCA15488 Warner 5219-37 Warner 5219-42 |
TCA15092 | John Deere TCA15092, TCA15488, Warner 5219-37, Warner 5219-42, Stens 255-216X, Xtreme X0356 | John Deere 7H17, 7G18, 7H19 | Commercial walk-behind path. Use the lead TCA15092 product when TCA15488 or Warner 5219-37 appears on the original clutch path. | View TCA15092 clutch |
John Deere EZtrak, Residential ZTrak & Lawn Tractor PTO Clutch Cross-Reference
These rows route common John Deere residential mower, EZtrak, and lawn tractor clutch numbers to the correct lead product path.
Table tip: Scroll sideways on mobile to view the full cross-reference table.
| Searched Part Number | Lead Product Path | Replaces / Cross-References | Main Platform | Critical Fitment Note | Product Link |
|---|---|---|---|---|---|
|
AM141536 AM134397 AM143390 |
AM141536 | John Deere AM141536, AM134397, AM143390, Stens 255-847X | John Deere X300, X500, EZtrak applications | Common X300 / X500 / EZtrak replacement path. Confirm original part number and mower configuration before ordering. | View AM141536 clutch |
|
AM141537 Warner 5219-128 Warner 5219-87 |
AM141537 | John Deere AM141537, Warner 5219-128, Warner 5219-87 | John Deere X300, Z355, Z425, Z445 | This path is handled by the AM141537 lead product page. Confirm the original clutch and connector before ordering. | View AM141537 clutch |
|
AM136787 AM137323 Warner 5219-88 Warner 5219-225 |
AM136787 | John Deere AM136787, AM137323, Warner 5219-88, Warner 5219-225, Stens 255-152, Xtreme references where applicable | John Deere Z225, Z425, Z445, Z465 | EZtrak / residential ZTrak path. Confirm deck size and original clutch number. | View AM136787 clutch |
|
AM141978 Warner 5219-126 |
AM141978 | John Deere AM141978, Warner 5219-126, Stens 255-130X, Xtreme X0335 | John Deere Z625, Z645, Z655 | EZtrak path. Match the original clutch number and pulley profile before ordering. | View AM141978 clutch |
|
AM136115 Warner 5219-83 Xtreme X0381 |
AM136115 | John Deere AM136115, Warner 5219-83, Xtreme X0381 | John Deere Z245, Z255, Z355E | Use this path only when the mower and original clutch match the AM136115 / 5219-83 family. | View AM136115 clutch |
|
GY21339 Warner 5219-113 Warner 5219-114 Xtreme X0425 |
GY21339 | John Deere GY21339, Warner 5219-113, Warner 5219-114, Xtreme X0425, Stens 255-299X | John Deere D140, D150, D155, LA145, L130 and related lawn tractor paths | Residential lawn tractor path. Verify original clutch number and mower deck configuration. | View GY21339 clutch |
|
GY20108 GY20652 GY20878 GY21340 Warner 5219-20 |
GY20878 | John Deere GY20878, GY20108, GY20652, GY21340, Warner 5219-20 | John Deere D140, L120, LA145 and related lawn tractor paths | Use the GY20878 lead product path when these searched numbers match the original clutch family. | View GY20878 clutch |
|
AM126100 Warner 5219-1 Warner 5219-221 |
AM126100 | John Deere AM126100, Warner 5219-1, Warner 5219-221 | John Deere lawn tractor applications | Match the original clutch number and specs. Do not substitute based on mower brand alone. | View AM126100 clutch |
John Deere STX, LX, GT, GX & Garden Tractor PTO Clutch Cross-Reference
Older John Deere lawn and garden tractor clutches are especially easy to misorder because STX yellow-deck and black-deck paths split by deck style and serial number.
Table tip: Scroll sideways on mobile to view the full cross-reference table.
| Searched Part Number | Lead Product Path | Replaces / Cross-References | Main Platform | Critical Fitment Note | Product Link |
|---|---|---|---|---|---|
|
AM122969 AM100979 AM118969 Warner 5215-35 |
AM100979 | John Deere AM100979, AM122969, AM118969, Warner 5215-35 | John Deere STX38 Yellow Deck and related older John Deere lawn tractors | Yellow-deck STX path. Do not confuse with STX38 / STX46 black-deck serial paths. | View AM100979 clutch |
|
AM119683 Warner 5217-6 Warner 5217-7 Warner 5217-9 Warner 5217-27 Warner 5217-28 Warner 5217-35 |
AM119683 | John Deere AM119683, Warner 5217-series references, Stens 255-511 | John Deere STX38 and STX46 Black Deck | Black-deck early serial path. Fits STX38 and STX46 black-deck applications at serial 270000 and lower. | View AM119683 clutch |
|
AM121972 Warner 5217-8 Warner 5217-20 Warner 5217-36 Warner 5217-38 |
AM121972 | John Deere AM121972, Warner 5217-8, 5217-20, 5217-36, 5217-38, Stens 255-141 | John Deere STX38 and STX46 Black Deck | Black-deck later serial path. Fits STX38 and STX46 black-deck applications at serial 270001 and higher. | View AM121972 clutch |
|
AM123038 AM38260 AM119971 Warner 5215-112 Warner 5215-55 Warner 5215-92 Warner 5215-96 |
AM119971 | John Deere AM119971, AM123038, AM38260, Warner 5215-112, 5215-55, 5215-92, 5215-96, Stens 255-132 | John Deere LX172, LX173, LX176, LX178 | LX-series lead path. Confirm original clutch number and wiring before ordering. | View AM119971 clutch |
|
AM118625 AM106365 AM116654 Warner 5215-27 |
AM118625 | John Deere AM118625, AM106365, AM116654, Warner 5215-27, Stens 255-248X | John Deere F510, F525 | Front mower path. Confirm 1-1/8 inch bore and pulley profile before ordering. | View AM118625 clutch |
|
AM115091 AM116233 AM123123 |
AM123123 | John Deere AM123123, AM115091, AM116233 and related replacement numbers | John Deere lawn tractor and walk-behind mower applications | Use the AM123123 lead product path when the original clutch number matches this replacement family. | View AM123123 clutch |
|
AM115093 AM108601 AM119536 |
AM119536 | John Deere AM119536, AM115093, AM108601 | John Deere 240, 345, GT275 and related lawn tractor paths | Confirm original clutch number, bore, connector, and mower configuration before ordering. | View AM119536 clutch |
|
AM118970 AM123285 AM130328 Ogura MA-GT-JD24 |
AM130328 | John Deere AM130328, AM118970, AM123285, Ogura MA-GT-JD24, Stens 255-829X | John Deere GT275, 320, Sabre, Scotts and related paths | Ogura-style lead path. Confirm the original clutch number and mounting profile. | View AM130328 clutch |
|
AM126102 AM131779 Ogura MA-GT-JD23 Ogura MA-GT-JD23BF |
AM131779 | John Deere AM131779, AM126102, Ogura MA-GT-JD23, MA-GT-JD23BF, Stens 255-831X, Rotary 15779 | John Deere 325, 335, 345, GX335, GX345, GX355 | Garden tractor Ogura path. Match the original clutch number and serial/application details before ordering. | View AM131779 clutch |
|
AM131778 AM133209 Ogura GT1A-JD10 |
AM133209 | John Deere AM133209, AM131778, Ogura GT1A-JD10, Stens 255-910X, Xtreme X0422 | John Deere GX335, GX345 serial 120001 and higher | Serial-sensitive garden tractor path. Confirm the serial number before ordering. | View AM133209 clutch |
How to Use This John Deere PTO Clutch Index
- Find the number from your old clutch, mower manual, parts diagram, or dealer lookup.
- Match that searched number to the lead product path in the table above.
- Open the lead product page and verify the final fitment details.
- Confirm physical specs before installation, including bore size, pulley diameter, rotation, connector, anti-rotation setup, and mounting profile. Before mounting the clutch, review the PTO clutch installation guide.
If your mower has a serial-number break, deck-size split, or conflicting marketplace fitment, do not guess. Check the original clutch number and compare photos before ordering.
Common John Deere PTO Clutch Fitment Traps
- TCA19813 and TCA21167 are not universal substitutes: they belong to different serial-number paths on several John Deere ZTrak applications.
- TCA19812 belongs under the TCA21168 lead path: do not merge it into unrelated 7.2-inch pulley clutch listings.
- Z820A deck size matters: 48-inch and 54-inch paths can differ from the Z820A 60-inch deck clutch path.
- STX38 Yellow Deck and Black Deck are different: do not order by STX38 alone.
- Warner and Ogura numbers are useful, but not enough by themselves: always match the clutch family and physical specs.
FAQ
What is a John Deere PTO clutch cross-reference?
A John Deere PTO clutch cross-reference connects OEM numbers, superseded numbers, and aftermarket references to the correct replacement clutch path. Examples include John Deere numbers, Warner numbers, Ogura numbers, Stens numbers, Xtreme numbers, Oregon numbers, Rotary numbers, and 8TEN numbers.
Why does PTO Direct USA use a lead product path?
Many old PTO clutch numbers are superseded, replaced, or listed under manufacturer cross-reference numbers. A lead product path keeps those searches organized so buyers land on one clean product page instead of multiple duplicate or conflicting listings.
Are all numbers in a cross-reference row interchangeable?
No. The row shows the replacement path used by PTO Direct USA, but final fitment still depends on mower model, serial number, deck size, bore size, pulley diameter, rotation, connector, anti-rotation setup, and mounting profile.
What should I do if my John Deere part number appears in more than one marketplace listing?
Do not rely on marketplace listings alone. Match the original clutch number and physical specs, then use the lead PTO Direct USA product page to confirm the correct replacement path.
Can PTO Direct USA help confirm my John Deere clutch?
Yes. Email support@ptodirectusa.com with your mower model, serial number, deck size, original clutch number, and clear photos of the old clutch, wiring connector, pulley, anti-rotation setup, and belt routing.
Need to browse instead? Shop the full John Deere PTO clutch collection or the full electric PTO clutch catalog.
